Unified API

Overview

The Unified API provides a consistent REST interface to access health data regardless of the source wearable device. Instead of implementing separate integrations for Garmin, Apple Health, Whoop, and other providers, you make standardized API calls and receive normalized data.

All API endpoints are documented interactively at http://localhost:8000/docs when running Open Wearables.

API Architecture

Base URL

All API requests use the base URL:

http://localhost:8000/api/v1

For production deployments, replace with your hosted domain.

Authentication

All requests require an API key in the Authorization header:

curl -H "Authorization: Bearer YOUR_API_KEY" \
  http://localhost:8000/api/v1/users

API keys provide full access to your data. Keep them secure and never commit them to version control.

Response Format

All endpoints return JSON responses with consistent structure:

{
  "id": "550e8400-e29b-41d4-a716-446655440000",
  "email": "[email protected]",
  "first_name": "John",
  "last_name": "Doe",
  "created_at": "2024-03-07T12:00:00Z"
}

Error responses include detailed messages:

{
  "detail": "User not found"
}

Core Endpoints

User Management

List Users

GET /api/v1/users

Query Parameters:

Parameter	Type	Description
`search`	string	Filter by name or email
`limit`	integer	Max results (default: 50)
`offset`	integer	Skip N results

Response:

[
  {
    "id": "550e8400-e29b-41d4-a716-446655440000",
    "email": "[email protected]",
    "first_name": "John",
    "last_name": "Doe",
    "created_at": "2024-03-07T12:00:00Z"
  }
]

Get User by ID

GET /api/v1/users/{user_id}

Path Parameters:

Parameter	Type	Description
`user_id`	UUID	User identifier

Response:

{
  "id": "550e8400-e29b-41d4-a716-446655440000",
  "email": "[email protected]",
  "first_name": "John",
  "last_name": "Doe",
  "created_at": "2024-03-07T12:00:00Z",
  "updated_at": "2024-03-07T15:30:00Z"
}

Create User

POST /api/v1/users
Content-Type: application/json

{
  "email": "[email protected]",
  "first_name": "Jane",
  "last_name": "Smith"
}

Request Body:

Field	Type	Required	Description
`email`	string	Yes	Valid email address
`first_name`	string	No	User’s first name
`last_name`	string	No	User’s last name

Response: 201 Created

{
  "id": "660e8400-e29b-41d4-a716-446655440000",
  "email": "[email protected]",
  "first_name": "Jane",
  "last_name": "Smith",
  "created_at": "2024-03-07T16:45:00Z"
}

Update User

PATCH /api/v1/users/{user_id}
Content-Type: application/json

{
  "first_name": "Jane Updated"
}

Partial Updates Supported: Only include fields you want to change.Response: 200 OK

Delete User

DELETE /api/v1/users/{user_id}

Response: 204 No Content

This permanently deletes the user and all associated health data. This action cannot be undone.

Health Data Access

Get Heart Rate Data

GET /api/v1/users/{user_id}/health/heart-rate?start_date=2024-03-01&end_date=2024-03-07

Query Parameters:

Parameter	Type	Description
`start_date`	ISO 8601	Start of date range
`end_date`	ISO 8601	End of date range
`source`	string	Filter by provider (garmin, polar, etc.)

Response:

[
  {
    "timestamp": "2024-03-07T08:00:00Z",
    "value": 72,
    "unit": "bpm",
    "source": "garmin",
    "confidence": 0.95
  }
]

Get Step Count

GET /api/v1/users/{user_id}/health/steps?start_date=2024-03-01&end_date=2024-03-07

Returns daily step counts aggregated from all sources.Response:

[
  {
    "date": "2024-03-07",
    "steps": 10500,
    "source": "apple",
    "goal": 10000,
    "goal_met": true
  }
]

Get Sleep Sessions

GET /api/v1/users/{user_id}/health/sleep?start_date=2024-03-01&end_date=2024-03-07

Response:

[
  {
    "id": "770e8400-e29b-41d4-a716-446655440000",
    "start_time": "2024-03-06T22:30:00Z",
    "end_time": "2024-03-07T06:45:00Z",
    "duration_minutes": 495,
    "stages": {
      "deep": 120,
      "light": 240,
      "rem": 90,
      "awake": 45
    },
    "quality_score": 85,
    "source": "whoop"
  }
]

Get Workouts

GET /api/v1/users/{user_id}/workouts?start_date=2024-03-01&end_date=2024-03-07

Query Parameters:

Parameter	Type	Description
`workout_type`	string	Filter by activity (running, cycling, etc.)
`cursor`	string	Pagination cursor for next page
`limit`	integer	Results per page (default: 20)

Response:

{
  "items": [
    {
      "id": "880e8400-e29b-41d4-a716-446655440000",
      "user_id": "550e8400-e29b-41d4-a716-446655440000",
      "workout_type": "running",
      "start_time": "2024-03-07T07:00:00Z",
      "duration_minutes": 45,
      "distance_meters": 8000,
      "calories": 450,
      "avg_heart_rate": 155,
      "max_heart_rate": 178,
      "source": "strava"
    }
  ],
  "next_cursor": "eyJpZCI6Ijg4MGU4NDAwIn0",
  "has_more": true
}

Get Body Metrics

GET /api/v1/users/{user_id}/health/body?start_date=2024-03-01&end_date=2024-03-07

Response:

[
  {
    "date": "2024-03-07",
    "weight_kg": 75.5,
    "body_fat_percentage": 18.5,
    "bmi": 23.2,
    "source": "garmin"
  }
]

Provider Connections

Get User Connections

GET /api/v1/users/{user_id}/connections

Lists all provider connections for a user.Response:

[
  {
    "id": "990e8400-e29b-41d4-a716-446655440000",
    "user_id": "550e8400-e29b-41d4-a716-446655440000",
    "provider": "garmin",
    "status": "active",
    "last_synced_at": "2024-03-07T12:00:00Z",
    "created_at": "2024-02-01T10:00:00Z"
  }
]

Trigger Manual Sync

POST /api/v1/users/{user_id}/connections/{provider}/sync

Manually triggers data synchronization for a specific provider.Response: 202 Accepted

{
  "task_id": "task-abc123",
  "status": "queued",
  "message": "Sync task queued successfully"
}

Disconnect Provider

DELETE /api/v1/users/{user_id}/connections/{provider}

Revokes OAuth tokens and disconnects the provider.Response: 204 No Content

Data Normalization

Open Wearables normalizes data from different providers into consistent formats:

Units Standardization

Distance
Weight
Heart Rate
Timestamps

All distances converted to meters:

{
  "distance_meters": 8000,
  "distance_km": 8.0,
  "distance_miles": 4.97
}

All weights in kilograms:

{
  "weight_kg": 75.5,
  "weight_lbs": 166.4
}

All heart rates in beats per minute:

{
  "value": 72,
  "unit": "bpm"
}

All timestamps in ISO 8601 UTC:

{
  "timestamp": "2024-03-07T12:00:00Z"
}

Workout Type Mapping

Common workout types are standardized across providers:

[
  "running",
  "cycling",
  "swimming",
  "walking",
  "yoga",
  "strength_training",
  "cardio",
  "other"
]

Provider-specific types are mapped to standard categories in backend/app/mappings.py.

Rate Limiting

API rate limits protect the service from abuse:

Per API Key: 1000 requests per hour
Per IP: 100 requests per minute (unauthenticated)

Rate limit headers included in all responses:

X-RateLimit-Limit: 1000
X-RateLimit-Remaining: 987
X-RateLimit-Reset: 1678195200

Contact support if you need higher rate limits for your use case.

Pagination

Large result sets use cursor-based pagination:

# First page
GET /api/v1/users/USER_ID/workouts?limit=20

# Response includes next_cursor
{
  "items": [...],
  "next_cursor": "eyJpZCI6Ijg4MGU4NDAwIn0",
  "has_more": true
}

# Next page
GET /api/v1/users/USER_ID/workouts?limit=20&cursor=eyJpZCI6Ijg4MGU4NDAwIn0

Error Handling

The API returns standard HTTP status codes:

Code	Meaning	Description
`200`	OK	Request succeeded
`201`	Created	Resource created successfully
`204`	No Content	Request succeeded, no body returned
`400`	Bad Request	Invalid request parameters
`401`	Unauthorized	Missing or invalid API key
`404`	Not Found	Resource doesn’t exist
`429`	Too Many Requests	Rate limit exceeded
`500`	Internal Server Error	Server error (contact support)

Error Response Format:

{
  "detail": "User not found",
  "status_code": 404,
  "error_code": "USER_NOT_FOUND"
}

SDK Examples

Python
TypeScript

import httpx

class OpenWearablesClient:
    def __init__(self, api_key: str, base_url: str = "http://localhost:8000"):
        self.api_key = api_key
        self.base_url = base_url
        self.client = httpx.Client(
            headers={"Authorization": f"Bearer {api_key}"},
            base_url=base_url,
            timeout=30.0
        )

    def get_users(self, search: str | None = None):
        params = {"search": search} if search else {}
        response = self.client.get("/api/v1/users", params=params)
        response.raise_for_status()
        return response.json()

    def get_heart_rate(self, user_id: str, start_date: str, end_date: str):
        response = self.client.get(
            f"/api/v1/users/{user_id}/health/heart-rate",
            params={"start_date": start_date, "end_date": end_date}
        )
        response.raise_for_status()
        return response.json()

# Usage
client = OpenWearablesClient(api_key="your-api-key")
users = client.get_users()
heart_rate = client.get_heart_rate(
    user_id="550e8400-e29b-41d4-a716-446655440000",
    start_date="2024-03-01",
    end_date="2024-03-07"
)

interface User {
  id: string;
  email: string;
  first_name?: string;
  last_name?: string;
  created_at: string;
}

class OpenWearablesClient {
  private apiKey: string;
  private baseUrl: string;

  constructor(apiKey: string, baseUrl: string = "http://localhost:8000") {
    this.apiKey = apiKey;
    this.baseUrl = baseUrl;
  }

  private async request<T>(endpoint: string, options?: RequestInit): Promise<T> {
    const response = await fetch(`${this.baseUrl}${endpoint}`, {
      ...options,
      headers: {
        "Authorization": `Bearer ${this.apiKey}`,
        "Content-Type": "application/json",
        ...options?.headers,
      },
    });

    if (!response.ok) {
      throw new Error(`API error: ${response.statusText}`);
    }

    return response.json();
  }

  async getUsers(search?: string): Promise<User[]> {
    const params = new URLSearchParams();
    if (search) params.append("search", search);

    return this.request<User[]>(`/api/v1/users?${params}`);
  }

  async getHeartRate(userId: string, startDate: string, endDate: string) {
    const params = new URLSearchParams({
      start_date: startDate,
      end_date: endDate,
    });

    return this.request(
      `/api/v1/users/${userId}/health/heart-rate?${params}`
    );
  }
}

// Usage
const client = new OpenWearablesClient("your-api-key");
const users = await client.getUsers();
const heartRate = await client.getHeartRate(
  "550e8400-e29b-41d4-a716-446655440000",
  "2024-03-01",
  "2024-03-07"
);

WebSocket Support (Coming Soon)

Real-time data streaming via WebSockets:

const ws = new WebSocket('ws://localhost:8000/api/v1/stream');

ws.onmessage = (event) => {
  const data = JSON.parse(event.data);
  console.log('New health data:', data);
};
