Export Options

ChartDB provides comprehensive export capabilities, allowing you to generate SQL DDL scripts, DBML definitions, and visual exports for documentation and deployment.

Export Formats

ChartDB supports multiple export formats for different use cases:

SQL DDL

Generate CREATE TABLE statements for any database

DBML

Export to Database Markup Language

PNG/SVG

Export diagram as image

JSON

Export raw diagram data

SQL Export

Native Dialect Export

Export SQL optimized for your diagram’s database type:

export const exportBaseSQL = ({
    diagram,
    targetDatabaseType,
    isDBMLFlow = false,
    onlyRelationships = false,
}: {
    diagram: Diagram;
    targetDatabaseType: DatabaseType;
    isDBMLFlow?: boolean;
    onlyRelationships?: boolean;
}): string => {
    // Export SQL for the target database
    switch (diagram.databaseType) {
        case DatabaseType.POSTGRESQL:
            return exportPostgreSQL({ diagram, onlyRelationships });
        case DatabaseType.MYSQL:
            return exportMySQL({ diagram, onlyRelationships });
        case DatabaseType.SQL_SERVER:
            return exportMSSQL({ diagram, onlyRelationships });
        case DatabaseType.SQLITE:
            return exportSQLite({ diagram, onlyRelationships });
    }
};

PostgreSQL Export

Full PostgreSQL DDL with advanced features:

CREATE TABLE public.users (
    id SERIAL PRIMARY KEY,
    email VARCHAR(255) NOT NULL UNIQUE,
    tags TEXT[],
    settings JSONB,
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
);

CREATE TABLE public.posts (
    id SERIAL PRIMARY KEY,
    user_id INT NOT NULL,
    title VARCHAR(255) NOT NULL,
    content TEXT,
    published BOOLEAN DEFAULT false,
    CONSTRAINT fk_posts_user_id
        FOREIGN KEY (user_id)
        REFERENCES public.users(id)
        ON DELETE CASCADE
);

MySQL Export

MySQL-specific DDL with engine and charset:

CREATE TABLE `users` (
  `id` INT AUTO_INCREMENT PRIMARY KEY,
  `email` VARCHAR(255) NOT NULL,
  `name` VARCHAR(100),
  `status` ENUM('active', 'inactive') DEFAULT 'active',
  `created_at` TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
  UNIQUE KEY `uk_users_email` (`email`),
  INDEX `idx_users_status` (`status`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_unicode_ci;

CREATE TABLE `posts` (
  `id` INT AUTO_INCREMENT PRIMARY KEY,
  `user_id` INT NOT NULL,
  `title` VARCHAR(255) NOT NULL,
  `content` TEXT,
  INDEX `idx_posts_user_id` (`user_id`),
  CONSTRAINT `fk_posts_user_id`
    FOREIGN KEY (`user_id`)
    REFERENCES `users` (`id`)
    ON DELETE CASCADE
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4;

SQL Server Export

T-SQL with SQL Server-specific syntax:

CREATE TABLE [dbo].[Users] (
    [Id] INT IDENTITY(1,1) PRIMARY KEY,
    [Email] NVARCHAR(255) NOT NULL,
    [Name] NVARCHAR(100),
    [CreatedAt] DATETIME2 DEFAULT GETDATE(),
    CONSTRAINT [UQ_Users_Email] UNIQUE ([Email])
);

CREATE NONCLUSTERED INDEX [IX_Users_Email]
ON [dbo].[Users] ([Email]);

CREATE TABLE [dbo].[Posts] (
    [Id] INT IDENTITY(1,1) PRIMARY KEY,
    [UserId] INT NOT NULL,
    [Title] NVARCHAR(255) NOT NULL,
    [Content] NVARCHAR(MAX),
    CONSTRAINT [FK_Posts_UserId]
        FOREIGN KEY ([UserId])
        REFERENCES [dbo].[Users] ([Id])
        ON DELETE CASCADE
);

SQLite Export

SQLite-compatible DDL:

CREATE TABLE users (
    id INTEGER PRIMARY KEY AUTOINCREMENT,
    email TEXT NOT NULL UNIQUE,
    name TEXT,
    created_at TEXT DEFAULT CURRENT_TIMESTAMP
);

CREATE INDEX idx_users_email ON users(email);

CREATE TABLE posts (
    id INTEGER PRIMARY KEY AUTOINCREMENT,
    user_id INTEGER NOT NULL,
    title TEXT NOT NULL,
    content TEXT,
    FOREIGN KEY (user_id) REFERENCES users(id) ON DELETE CASCADE
);

CREATE INDEX idx_posts_user_id ON posts(user_id);

Cross-Dialect Export

ChartDB supports deterministic cross-dialect conversions:

PostgreSQL to MySQL

export const exportPostgreSQLToMySQL = ({
    diagram,
    onlyRelationships = false,
}: {
    diagram: Diagram;
    onlyRelationships?: boolean;
}): string => {
    // Convert PostgreSQL types to MySQL equivalents
    // Handle unsupported features
    // Generate MySQL-compatible DDL
};

Type Mappings

PostgreSQL	MySQL	Notes
`SERIAL`	`INT AUTO_INCREMENT`	Auto-increment
`BIGSERIAL`	`BIGINT AUTO_INCREMENT`	Large auto-increment
`TEXT`	`TEXT`	Direct mapping
`BYTEA`	`BLOB`	Binary data
`BOOLEAN`	`TINYINT(1)`	True/False
`TIMESTAMP`	`DATETIME`	Date and time
`JSONB`	`JSON`	JSON data (MySQL 5.7+)
`TEXT[]`	`JSON`	Arrays converted to JSON
`UUID`	`CHAR(36)`	UUID as string

Array types are converted to JSON in MySQL. Check constraints may need manual adjustment.

PostgreSQL to SQL Server

export const exportPostgreSQLToMSSQL = ({
    diagram,
    onlyRelationships = false,
}: {
    diagram: Diagram;
    onlyRelationships?: boolean;
}): string => {
    // Convert PostgreSQL types to SQL Server equivalents
    // Handle schema differences
    // Generate T-SQL DDL
};

Type Mappings

PostgreSQL	SQL Server	Notes
`SERIAL`	`INT IDENTITY(1,1)`	Auto-increment
`TEXT`	`NVARCHAR(MAX)`	Unicode text
`BYTEA`	`VARBINARY(MAX)`	Binary data
`BOOLEAN`	`BIT`	True/False
`TIMESTAMP`	`DATETIME2`	High precision
`JSONB`	`NVARCHAR(MAX)`	JSON as text
`UUID`	`UNIQUEIDENTIFIER`	Native UUID

Unsupported Features Detection

ChartDB detects features that don’t translate well:

interface UnsupportedFeature {
    type: 'array' | 'enum' | 'check_constraint' | 'index_type';
    tableName: string;
    fieldName?: string;
    description: string;
    suggestion: string;
}

const detectUnsupportedFeatures = (
    diagram: Diagram,
    targetDatabase: DatabaseType
): UnsupportedFeature[] => {
    const features: UnsupportedFeature[] = [];

    // Check for arrays (not supported in MySQL/SQL Server)
    // Check for PostgreSQL-specific index types
    // Check for enum types
    // Check for complex check constraints

    return features;
};

Warnings are included in export output:

-- WARNING: The following features are not fully supported:
-- 1. Array type 'tags' in table 'users' converted to JSON
-- 2. GIN index 'idx_users_tags' converted to regular index
-- 3. Check constraint uses PostgreSQL-specific regex

DBML Export

Export to DBML format with two variants:

Standard DBML

With standalone relationship definitions:

Table users {
  id int [pk, increment]
  email varchar(255) [unique, not null]
  name varchar(100)
  created_at timestamp [default: `now()`]

  Note: 'User accounts table'
}

Table posts {
  id int [pk, increment]
  user_id int [not null]
  title varchar(255) [not null]
  content text
}

Ref: posts.user_id > users.id

Inline DBML

With inline relationship references:

Table users {
  id int [pk, increment]
  email varchar(255) [unique, not null]
  name varchar(100)
  created_at timestamp [default: `now()`]
}

Table posts {
  id int [pk, increment]
  user_id int [not null, ref: > users.id]
  title varchar(255) [not null]
  content text
}

DBML Export Features

Table Restoration
Enum Export
Index Restoration
Check Constraints
Comments

Schema information is preserved:

const restoreTableSchemas = (dbml: string, tables: DBTable[]): string => {
    // Add schema qualifiers to tables
    // Format: Table "schema"."table_name"
};

Custom types are exported as enums:

Enum order_status {
  pending
  processing
  shipped
  delivered
}

Table orders {
  id int [pk]
  status order_status [default: 'pending']
}

Index types are preserved:

Table posts {
  id int [pk]
  tags text[]

  Indexes {
    tags [type: gin, name: 'idx_posts_tags']
  }
}

Check constraints are included:

Table products {
  id int [pk]
  price decimal(10,2)
  quantity int

  checks {
    `price > 0` [name: 'check_positive_price']
    `quantity >= 0`
  }
}

Table and field notes:

Table users {
  id int [pk]
  email varchar [note: 'User email address']

  Note: 'Application user accounts'
}

DBML Conversion Pipeline

The DBML export uses a round-trip process:

Generate SQL

Export diagram to SQL for the diagram’s database type

Sanitize SQL

Clean SQL for DBML parser compatibility:

export const sanitizeSQLforDBML = (sql: string): string => {
    // Remove PostgreSQL-specific syntax
    // Fix constraint name duplicates
    // Handle self-referencing foreign keys
    // Normalize type casting
};

Parse to DBML

Use @dbml/core importer to convert SQL to DBML

Restore Features

Add back features lost in conversion:

Table schemas
Index types
Check constraints
Auto-increment attributes
Comments and notes

Convert References

Optionally convert to inline reference format

Only Relationships

Export just the foreign key constraints:

const sql = exportBaseSQL({
    diagram,
    targetDatabaseType: DatabaseType.POSTGRESQL,
    onlyRelationships: true, // Only FK constraints
});

Output:

-- Foreign key constraints
ALTER TABLE posts
ADD CONSTRAINT fk_posts_user_id
    FOREIGN KEY (user_id)
    REFERENCES users(id);

ALTER TABLE comments
ADD CONSTRAINT fk_comments_post_id
    FOREIGN KEY (post_id)
    REFERENCES posts(id);

Custom Type Handling

Control how custom types are exported:

const supportsCustomTypes = (databaseType: DatabaseType): boolean => {
    return databaseType === DatabaseType.POSTGRESQL;
};

// For databases without custom type support,
// enums are converted to CHECK constraints
if (!supportsCustomTypes(targetDatabase)) {
    // Convert enum to VARCHAR with CHECK
    // status VARCHAR(20) CHECK (status IN ('pending', 'active'))
}

Comment Support

Include table and column comments where supported:

const databaseTypesWithCommentSupport = [
    DatabaseType.POSTGRESQL,
    DatabaseType.MYSQL,
    DatabaseType.ORACLE,
];

if (databaseTypesWithCommentSupport.includes(targetDatabase)) {
    // Add COMMENT ON statements or inline comments
}

Visual Export

Export diagram as image:

PNG Export

Raster image for documentation

SVG Export

Vector image for scalability

Export Quality

Control export resolution and quality:

interface ExportImageOptions {
    format: 'png' | 'svg';
    quality?: number; // 0-100 for PNG
    backgroundColor?: string;
    padding?: number;
    includeAreas?: boolean;
    includeNotes?: boolean;
}

JSON Export

Export raw diagram data for backup or migration:

{
  "id": "diagram_123",
  "name": "E-commerce Database",
  "databaseType": "postgresql",
  "tables": [...],
  "relationships": [...],
  "customTypes": [...],
  "createdAt": "2024-03-04T10:30:00Z",
  "updatedAt": "2024-03-04T12:45:00Z"
}

This format preserves:

All table definitions
Field attributes and constraints
Relationships and cardinalities
Custom types and enums
Table positions and colors
Notes and areas
Metadata and timestamps

Export Caching

SQL exports are cached for performance:

const generateCacheKey = (
    diagram: Diagram,
    targetDatabaseType: DatabaseType,
    options: ExportOptions
): string => {
    return `${diagram.id}_${targetDatabaseType}_${JSON.stringify(options)}`;
};

const getFromCache = (key: string): string | null => {
    const cached = cache.get(key);
    if (cached && cached.timestamp > diagram.updatedAt) {
        return cached.sql;
    }
    return null;
};

Cache is invalidated when diagram changes.

Best Practices

For production deployments:

Review generated SQL before running on production databases
Test migrations on a staging environment first
Include comments for better documentation
Export both SQL and DBML for version control
Use cross-dialect warnings to identify compatibility issues
Validate foreign keys are in correct order

Advanced Export Features

Default Value Formatting

Default values are intelligently formatted:

const formatDefaultValue = (value: string): string => {
    // SQL keywords (no quotes)
    if (['TRUE', 'FALSE', 'NULL', 'CURRENT_TIMESTAMP'].includes(value)) {
        return value;
    }

    // Function calls (no quotes)
    if (value.includes('(') && value.includes(')')) {
        return value;
    }

    // Numbers (no quotes)
    if (/^-?\d+(\.\d+)?$/.test(value)) {
        return value;
    }

    // Strings (quoted and escaped)
    return `'${value.replace(/'/g, "''")}'`;
};

Identifier Quoting

Table and field names are quoted when needed:

const getQuotedTableName = (table: DBTable): string => {
    const needsQuoting = /[^a-zA-Z0-9_]/.test(table.name);

    if (table.schema) {
        return needsQuoting
            ? `"${table.schema}"."${table.name}"`
            : `${table.schema}.${table.name}`;
    }

    return needsQuoting ? `"${table.name}"` : table.name;
};

Troubleshooting

Foreign Keys Fail

Ensure referenced tables are created before referencing tables in the export order.

Type Conversion Issues

Review cross-dialect warnings for incompatible types and adjust manually.

Missing Features

Some database-specific features may not translate. Use native export when possible.

Character Encoding

For MySQL, ensure charset and collation settings match your application needs.

Next Steps

AI Migration

Use AI for advanced database migrations

Diagram Editor

Edit your diagram before export

Get Started

Core Features

Database Support

Guides

Self-Hosting

​Export Formats

SQL DDL

DBML

PNG/SVG

JSON

​SQL Export

​Native Dialect Export

​PostgreSQL Export

​MySQL Export

​SQL Server Export

​SQLite Export

​Cross-Dialect Export

​PostgreSQL to MySQL

​Type Mappings

​PostgreSQL to SQL Server

​Type Mappings

​Unsupported Features Detection

​DBML Export

​Standard DBML

​Inline DBML

​DBML Export Features

​DBML Conversion Pipeline

​Export Options

​Only Relationships

​Custom Type Handling

​Comment Support

​Visual Export

PNG Export

SVG Export

​Export Quality

​JSON Export

​Export Caching

​Best Practices

​Advanced Export Features

​Default Value Formatting

​Identifier Quoting

​Troubleshooting

​Next Steps

AI Migration

Diagram Editor

Build docs developers (and LLMs) love

Export Formats

SQL Export

Native Dialect Export

PostgreSQL Export

MySQL Export

SQL Server Export

SQLite Export

Cross-Dialect Export

PostgreSQL to MySQL

Type Mappings

PostgreSQL to SQL Server

Type Mappings

Unsupported Features Detection

DBML Export

Standard DBML

Inline DBML

DBML Export Features

DBML Conversion Pipeline

Export Options

Only Relationships

Custom Type Handling

Comment Support

Visual Export

Export Quality

JSON Export

Export Caching

Best Practices

Advanced Export Features

Default Value Formatting

Identifier Quoting

Troubleshooting

Next Steps
